Unipolar and Bipolar Half Coil, because we’re using less turns, doesn’t give us great low speed torque, but because of the low inductance, holds the torque out to high speeds.
Bipolar Series uses the full coil so it gives very good low speed torque but because of the high inductance, the torque drops off rapidly.
Bipolar Parallel also uses the full coil so it gives good low speed performance and its low inductance allows the torque to be held out to high speeds. But remember, we must increase current by 40% to get those advantages.
| Connections | Resistance (Ohms) |
Inductance (mH) |
Current (A) |
Voltage (V) |
Holding Torque (oz-in) |
| Unipolar | Same as NamePlate | Same as NamePlate | Same as NamePlate | Same as NamePlate |
Same as NamePlate |
| Bipolar Series | NamePlate X 2 | NamePlate X 4 | NamePlate X 0.707 | NamePlate X 1.414 |
NamePlate X 1.414 |
| Bipolar Half Coil | Same as NamePlate | Same as NamePlate | Same as NamePlate | Same as NamePlate |
Same as NamePlate |
| Bipolar Parallel | NamePlate X 0.5 | Same as NamePlate | NamePlate X 1.414 | NamePlate X 0.707 |
NamePlate X 1.414 |
| Driver | Motor Choices |
What to Do | How to Do It | End Result | |
| Unipolar (6 Leads) |
6 Lead Motor | Use as is (Unipolar) |
6 Leads | ||
| 8 Lead Motor | Convert to Unipolar |
Tie yellow and orange together and use AND Tie white and brown together and use |
6 Leads | ||
| Bipolar (4 Leads) |
6 Lead Motor | Convert to Series |
Tape off yellow and white leads and don’t use | 4 Leads | |
| Convert to Half Coil |
Tape off black and red leads OR Tape off green and blue leads |
4 Leads | |||
| 8 Lead Motor | Convert to Series |
Connect yellow and orange and tape off AND Connect white and brown and tape off |
4 Leads | ||
| Convert to Parallel |
Tie black and orange together AND Tie yellow and green together AND Tie red and brown together AND Tie white and blue together |
4 Leads | |||
| Convert to Half Coil |
Tape off black, yellow, red, and white OR Tape off orange, green, brown, and blue |
4 Leads | |||
Testing the new IC from Toshiba, THB6064AH. Going well and will supply updates as I test further. stay tuned. For now I have attached the only instruction and datasheets I have for this chip. Looking to be rock solid and may be my choice for my upcoming DIY Homemade CNC.
dP—
Here’s some links to PDF’s on this IC:
Differences between THB6064H and THB6064AH
Learn More
There will be a pause in the update for the next month(s) as my shop moves home. With this move comes a complete renovation of a section of my home. I maybe posting about this as there are many solutions I have to complete that may help others out there.
My first project is/was ripping out 3 old brink molded windows and replacing them. Of course they were special order and it took nearly a month to get these in from Home Depot. It was an interesting learning curve. There has been a lot of down pours the past week so I got 2 complete. 1 more to go.
I think I’ll post Pics and videos on the install and let others tear my work apart. Some others may find it informative
Learn More
Got in an older DV9000 I felt like fixing. Dead as a door nail. No power. No Lights. Power cable held together by tape. So lets dig in and see what we find shall we??? Maybe this will help others as I am assuming this laptop has a series of problems.
UPDATES TO FOLLOW—->
Learn More
